JK Smart BMS 150A with 0.6A Active Balancer | 8S-20S LiFePO4, Lithium-Ion & LTO Battery Management System | 300A Peak Current | Electric Bike, 24V, 48V, 60V & 72V Battery Packs
Rs 13,500
Govt Tax: +Rs 540.00(Govt Tax 4%)
JK Smart BMS 150A with 0.6A Active Balancer | 8S-20S LiFePO4, Lithium-Ion & LTO Battery Management System | 300A Peak Current | Electric Bike, 24V, 48V, 60V & 72V Battery Packs
The JK-BD6A20S15P Smart Active Balance BMS is a high-performance Battery Management System designed for Electric Bike batteries, E-Rickshaw batteries, and 8S-20S lithium battery packs
Featuring 0
6A Active Balancing, 150A continuous current, and 300A peak current, this smart BMS helps maximize battery life, improve performance, and ensure safe operation
Compatible with LiFePO4, Lithium-Ion, and LTO batteries, it is ideal for building 24V, 48V, 60V, and 72V battery packs
Ke
Tip: Scroll inside the gallery to browse all images.
Product Description
Short Description
The JK-BD6A20S15P Smart Active Balance BMS is a high-performance Battery Management System designed for Electric Bike batteries, E-Rickshaw batteries, and 8S-20S lithium battery packs. Featuring 0.6A Active Balancing, 150A continuous current, and 300A peak current, this smart BMS helps maximize battery life, improve performance, and ensure safe operation. Compatible with LiFePO4, Lithium-Ion, and LTO batteries, it is ideal for building 24V, 48V, 60V, and 72V battery packs.
Key Highlights
✅ 150A Continuous Charge & Discharge Current
✅ 300A Peak Current Support
✅ 0.6A Active Balancing Technology
✅ Supports 8S-20S Battery Packs
✅ Ideal for Electric Bike Batteries
✅ Suitable for E-Rickshaw & Electric Scooter Batteries
✅ Supports 24V, 48V, 60V & 72V Battery Systems
✅ LiFePO4, Lithium-Ion & LTO Compatible
✅ Smart Battery Protection System
✅ Cell Voltage Balancing
✅ Overcharge Protection
✅ Over-Discharge Protection
✅ Overcurrent Protection
✅ Short Circuit Protection
✅ Temperature Protection
✅ Extended Battery Life
Product Features
Powerful 150A Output
Designed for high-current applications requiring stable and reliable power delivery for electric vehicles and energy storage systems.
300A Peak Current Capability
Handles high startup and acceleration loads with ease, making it ideal for electric bikes, electric scooters, and other EV applications.
Active Balancing Technology
The built-in 0.6A Active Balancer continuously transfers energy between cells, reducing voltage differences and maximizing battery efficiency.
Multi-Chemistry Support
Compatible with:
* LiFePO4 Batteries
* Lithium-Ion Batteries
* LTO Batteries
Complete Battery Protection
Provides comprehensive protection against:
Overcharge
Over-Discharge
Overcurrent
Short Circuit
High Temperature
Low Temperature
Cell Imbalance
Applications
✔️ Electric Bike Battery Packs
✔️ Electric Scooter Batteries
✔️ E-Rickshaw Battery Systems
✔️ 24V Lithium Battery Packs
✔️ 48V LiFePO4 Battery Packs
✔️ 60V Electric Bike Batteries
✔️ 72V Electric Bike Batteries
✔️ Solar Energy Storage Systems
✔️ UPS Backup Batteries
✔️ Portable Power Stations
✔️ Industrial Energy Storage Projects
Frequently Asked Questions
The JK-BD6A20S15P is a Smart Battery Management System (BMS) designed to monitor, manage, and protect compatible lithium battery packs. It supports 8S to 20S battery configurations, with a 150A continuous discharge rating and 0.6A active cell balancing.
The JK-BD6A20S15P supports 8S to 20S battery configurations, making it suitable for battery packs with 8 to 20 cells connected in series, depending on the battery chemistry and required voltage.
Yes. An 8S LiFePO4 battery has a nominal voltage of approximately 25.6V, making the JK-BD6A20S15P suitable for compatible 24V-class LiFePO4 battery systems.
Yes. A typical 16S LiFePO4 battery has a nominal voltage of approximately 51.2V. Since the JK-BD6A20S15P supports 16S, it can be used for compatible 48V-class LiFePO4 battery systems.
Yes. Depending on the battery chemistry and series configuration, the 8S–20S support range allows this BMS to be used for various higher-voltage lithium battery packs.
The JK-BD6A20S15P is rated for 150A continuous discharge current. Actual safe operating current also depends on the battery cells, cables, connectors, terminals, temperature, and overall system design.
The 0.6A active balancing function helps reduce voltage differences between individual cells by transferring energy between cells. This helps maintain a more balanced battery pack.
The active balancing function can help:
Reduce voltage differences between cells
Improve battery pack balance
Improve usable battery capacity
Maintain more consistent cell voltages
Improve overall battery performance
Support better long-term battery management
Yes. The JK-BD6A20S15P can be used for compatible LiFePO4 battery applications, provided that the correct battery chemistry, series configuration, and BMS parameters are selected.
The BMS can be used in various compatible lithium battery applications, including:
LiFePO4 battery packs
Solar energy storage systems
Inverter batteries
Home energy storage
Higher-voltage lithium battery systems
EV and electric vehicle batteries
Custom lithium battery packs
High-current battery applications
Yes. It can be used in compatible solar energy storage and inverter battery systems. Its 150A current rating makes it suitable for many high-current applications when the battery cells, inverter, cables, and other components are properly matched.
Yes, where the battery voltage and current requirements are compatible. The 8S–20S support range and 150A current rating make it suitable for various higher-voltage EV and electric mobility battery configurations.
JK Smart BMS models may include Bluetooth monitoring and mobile app functionality depending on the exact model and version. Please verify the communication features of the specific product version before purchase.
The BMS is designed to monitor and protect compatible battery systems against abnormal conditions such as over-voltage, under-voltage, over-current, and temperature-related conditions, according to the configured parameters and product version.
Yes, it can be suitable for a 150Ah lithium battery, depending on the battery's required charge and discharge current. BMS selection should consider battery chemistry, cell configuration, maximum current, and application requirements.
No. The 0.6A active balancing current and 150A continuous discharge rating are separate specifications.
The 0.6A rating refers to the active cell balancing function, while 150A refers to the BMS's rated continuous discharge capability.
The BMS supports 8S to 20S configurations.
For LiFePO4 batteries, examples include:
8S = approximately 25.6V nominal
16S = approximately 51.2V nominal
20S = approximately 64V nominal
Individual cells connected in series can develop differences in voltage and state of charge. Active balancing helps reduce these differences by transferring energy between cells, helping the battery pack operate more consistently.
The appropriate balancing current depends on the cell capacity, cell matching, battery configuration, and application. The 0.6A active balancing of the JK-BD6A20S15P is suitable for compatible battery packs where this balancing level meets the application's requirements.
Yes. It can be installed in a new compatible lithium battery pack. The battery chemistry, series cell count, current requirements, wiring, and BMS settings must be correctly matched.
The 150A rating represents the BMS's rated continuous discharge capability. However, the complete battery system must also be capable of safely supplying the required current. Battery cells, cables, connectors, terminals, temperature, and installation quality must all be considered.
The JK-BD6A20S15P is suitable for users looking for a 150A Smart BMS with 0.6A active balancing and 8S–20S support for compatible lithium battery systems, including solar storage, high-power inverter batteries, EV applications, and custom LiFePO4 battery packs.
Both models support 8S–20S configurations and provide 0.6A active balancing. The main difference is the continuous discharge rating:
JK-BD6A20S10P: 100A / 0.6A Active Balancing
JK-BD6A20S15P: 150A / 0.6A Active Balancing
The JK-BD6A20S15P is designed for applications requiring a higher continuous current rating.
Before purchasing, provide:
Battery chemistry
Battery voltage
Number of cells in series
Battery Ah capacity
Maximum load current
Maximum charging current
Inverter or controller model
Application type
You can purchase the JK-BD6A20S15P 150A 0.6A Active Balancer 8S–20S BMS from Voltpro Energy, subject to product availability.
Visit www.voltproenergy.com to check product availability, specifications, and purchasing information.
When purchasing, always verify the exact JK-BD6A20S15P model, 150A current rating, 0.6A active balancing, and 8S–20S configuration to ensure compatibility with your lithium battery system.
