Product Description
Product Description
The JK-BD6A8S10P Smart BMS is a high-performance Battery Management System designed for 4S to 8S lithium battery packs. It is suitable for LiFePO4, Lithium-Ion and LTO battery chemistries, making it a versatile solution for 12V and 24V battery systems.
With a powerful 0.6A Active Balancing System, the JK-BD6A8S10P actively transfers energy between cells to help maintain better cell voltage consistency. This improves battery pack performance and helps maximize usable battery capacity.
The BMS supports up to 100A continuous charging and discharging current, with a maximum instantaneous current rating of up to 200A. It also provides multiple battery protection functions including overcharge, over-discharge, over-current, short-circuit and temperature protection.
The integrated Bluetooth communication allows users to monitor battery information through a compatible mobile application, while display support provides convenient access to important battery parameters.
The JK-BD6A8S10P is an excellent choice for LiFePO4 battery packs, solar energy storage, inverter batteries, RVs, electric vehicles, electric bikes, mobility applications and other high-capacity lithium battery systems.
Product Highlights
JK-BD6A8S10P Smart BMS
4S–8S Battery Configuration
100A Continuous Charge Current
100A Continuous Discharge Current
200A Maximum Instantaneous Current
0.6A Active Cell Balancing
Supports LiFePO4, Lithium-Ion & LTO
Bluetooth Smart Monitoring
Display Support
Overcharge & Over-Discharge Protection
Over-Current Protection
Short-Circuit Protection
Temperature Protection
Coulomb Counter / Battery Capacity Monitoring
Common-Port Charging & Discharging
Designed for high-capacity lithium battery packs
Key Features
0.6A Active Cell Balancing
The JK-BD6A8S10P uses active balancing technology to transfer energy between battery cells instead of simply dissipating excess energy as heat. This helps maintain better cell voltage consistency and improves overall battery pack efficiency.
100A Continuous Current
With up to 100A continuous charging and discharging capability, this BMS is suitable for demanding lithium battery applications where reliable current handling is required.
4S–8S Battery Support
The BMS supports 4S to 8S battery configurations, making it suitable for different lithium battery pack designs. For LiFePO4 applications, this commonly covers 12.8V (4S) and 25.6V (8S) nominal battery configurations.
Multi-Chemistry Support
The JK-BD6A8S10P can be configured for different lithium battery chemistries, including:
LiFePO4
Lithium-Ion
LTO
Bluetooth Smart Monitoring
The built-in Bluetooth function allows compatible smartphones to monitor important battery parameters through the JK BMS application, including cell voltages, total battery voltage, current and protection status.
Comprehensive Battery Protection
The BMS continuously monitors the battery pack and provides protection against abnormal operating conditions such as:
Overcharge
Over-discharge
Over-current
Short circuit
Over-temperature
Abnormal cell voltage
Display Support
The BMS supports a compatible display for convenient monitoring of battery information and system status.
Technical Specifications
Specification Details
Brand JK / Jikong
Model JK-BD6A8S10P
BMS Type Smart Active Balancing BMS
Battery Chemistry LiFePO4 / Lithium-Ion / LTO
Battery Series 4S–8S
LiFePO4 Configuration 4S–8S
Lithium-Ion Configuration 4S–8S*
LTO Configuration 6S–8S*
Continuous Charge Current 100A
Continuous Discharge Current 100A
Maximum Instantaneous Current 200A
Active Balancing Current 0.6A
Balancing Type Active Energy Transfer
Communication Bluetooth
Display Support Yes
Charging & Discharging Port Common Port
Short-Circuit Protection Yes
Over-Current Protection Yes
Overcharge Protection Yes
Over-Discharge Protection Yes
Temperature Protection Yes
Coulomb Counter Yes
Cell Voltage Monitoring Yes
Mobile App Compatible JK BMS App
Operating Temperature Approx. -30°C to 70°C
Supply Voltage 7.5–36V
Maximum Cell Monitoring 8 Cells
Application Lithium Battery Pack Management
*Exact series range depends on battery chemistry and configuration. Always configure the BMS according to the actual cell chemistry and pack voltage.
Suitable Applications
The JK-BD6A8S10P can be used in a wide range of lithium battery applications, including:
12V LiFePO4 Batteries
24V LiFePO4 Batteries
Solar Energy Storage Systems
Inverter Battery Packs
RV & Camper Battery Systems
Electric Bikes
Electric Vehicles
Mobility Scooters
Marine Battery Systems
Backup Power Systems
Off-Grid Energy Storage
DIY Lithium Battery Packs
High-Capacity Energy Storage Applications
Why Choose JK-BD6A8S10P?
The JK-BD6A8S10P combines high-current battery protection, active cell balancing and smart Bluetooth monitoring in one compact BMS.
Its 0.6A active balancing helps improve cell consistency, while the 100A continuous current capability makes it suitable for high-power battery applications. Bluetooth monitoring gives users convenient access to battery information and protection parameters.
For customers building a reliable 12V or 24V LiFePO4 battery, this JK Smart BMS provides an advanced solution for battery protection and cell management.
Important Compatibility Note
Before purchasing or installing the BMS, confirm:
Battery chemistry
Number of cells in series
Maximum charging current
Maximum continuous load current
Battery cell voltage range
Required communication interface
Available installation space
For best performance, the battery cells should be properly matched and the BMS should be configured according to the selected cell chemistry.
Frequently Asked Questions
The JK-BD6A8S10P is a Smart Battery Management System (BMS) designed for compatible lithium battery packs. It supports 4S to 8S battery configurations, with a 100A current rating and 0.6A active cell balancing.
The JK-BD6A8S10P supports 4S to 8S lithium battery configurations, making it suitable for various low- and medium-voltage battery systems.
Yes. It can be used with compatible LiFePO4 (LFP) battery packs when the correct battery chemistry, series configuration and BMS parameters are selected.
Yes. A typical 4S LiFePO4 battery has a nominal voltage of approximately 12.8V, making this BMS suitable for compatible 12V-class LiFePO4 battery systems.
Yes. An 8S LiFePO4 battery has a nominal voltage of approximately 25.6V, and the JK-BD6A8S10P supports up to 8S.
The JK-BD6A8S10P is rated at 100A. Actual safe operating current depends on the battery cells, cables, busbars, terminals, connectors, temperature and complete system design.
The 0.6A active balancing function transfers energy between individual cells to help reduce voltage differences and maintain better balance throughout the battery pack.
The active balancing function can help:
Reduce voltage differences between cells
Improve battery pack balance
Improve usable battery capacity
Maintain more consistent cell voltages
Improve overall battery performance
Help maintain better cell balance over time
No. The 0.6A active balancing current and 100A current rating are separate specifications. The 0.6A refers to cell balancing, while 100A refers to the BMS's rated current capability.
Yes. It can be used in compatible 12V and 24V solar energy storage and lithium battery systems, provided the battery configuration and current requirements are compatible.
Yes. It can be used in compatible inverter battery systems. The inverter's maximum current requirements should be checked before selecting the BMS.
Yes. It can be used in compatible EV, electric bike and electric mobility battery applications where the voltage, chemistry and current requirements match the BMS specifications.
Yes. It can be suitable for a 100Ah lithium battery, provided that the battery cells and complete system can safely handle the required charging and discharging current.
Yes. A 100A BMS can be used with a 200Ah LiFePO4 battery when the required continuous charge and discharge current is within the BMS rating and the battery cells are suitable for the application.
The BMS supports 4S to 8S configurations.
For LiFePO4 batteries, common examples include:
4S = approximately 12.8V nominal
8S = approximately 25.6V nominal
Individual cells connected in series can develop differences in voltage and state of charge. Active balancing helps reduce these differences by transferring energy between cells.
Yes. The 0.6A active balancing function can be useful for compatible lithium battery packs. The appropriate balancing current depends on cell capacity, cell matching and battery configuration.
Yes. It can be installed in a compatible new lithium battery pack. The battery chemistry, series cell count, current requirements, wiring and BMS settings must be correctly matched.
The BMS is rated at 100A, but a 100A application requires the entire battery system to be designed for the required current. Battery cells, busbars, cables, terminals, connectors, fuses and thermal management must all be appropriately rated.
Yes. A 4S LiFePO4 battery is approximately 12.8V nominal, and the JK-BD6A8S10P supports 4S. It can be suitable for a 12.8V 100Ah system when the battery and load requirements are compatible.
Yes. An 8S LiFePO4 battery is approximately 25.6V nominal, and the JK-BD6A8S10P supports 8S.
The BMS can be used for compatible applications such as:
12V LiFePO4 battery packs
24V LiFePO4 battery packs
Solar energy storage
Inverter batteries
UPS battery systems
EV and electric mobility applications
Lithium battery packs
Custom battery systems
Before purchasing, check:
Battery chemistry
Battery voltage
Number of cells in series
Battery capacity (Ah)
Maximum charging current
Maximum discharge current
Inverter or controller specifications
Required BMS features
You can purchase the JK-BD6A8S10P 100A / 0.6A Active Balancer 4S–8S BMS from Voltpro Energy, subject to product availability.
Visit www.voltproenergy.com to check product availability, specifications and purchasing information.
The JK-BD6A8S10P is suitable for users looking for a 100A Smart BMS with 0.6A active balancing and 4S–8S support for compatible 12V and 24V-class lithium battery systems, including solar batteries, inverter batteries, UPS systems, EV applications and custom LiFePO4 battery packs.
