JK-PB2A16S10P Inverter BMS 100A with 2A Active Balancer | 8S-16S LiFePO4, Lithium-Ion & LTO Battery Management System | CAN, RS485, RS232 & Bluetooth Support | V19 Version
Rs 19,000
Govt Tax: +Rs 760.00(Govt Tax 4%)
JK-PB2A16S10P Inverter BMS 100A with 2A Active Balancer | 8S-16S LiFePO4, Lithium-Ion & LTO Battery Management System | CAN, RS485, RS232 & Bluetooth Support | V19 Version
The JK-PB2A16S10P Smart Inverter BMS is a premium Battery Management System designed for solar energy storage batteries, inverter battery banks, UPS systems, and lithium battery packs
Featuring a powerful 2A Active Balancer, 100A continuous charge/discharge current, and advanced communication protocols including Bluetooth, RS232, RS485, and CAN, it ensures superior battery protection, efficient balancing, and seamless inverter integration
Compatible with LiFePO4, Lithium-Io
Tip: Scroll inside the gallery to browse all images.
Product Description
Short Description
The JK-PB2A16S10P Smart Inverter BMS is a premium Battery Management System designed for solar energy storage batteries, inverter battery banks, UPS systems, and lithium battery packs. Featuring a powerful 2A Active Balancer, 100A continuous charge/discharge current, and advanced communication protocols including Bluetooth, RS232, RS485, and CAN, it ensures superior battery protection, efficient balancing, and seamless inverter integration.
Compatible with LiFePO4, Lithium-Ion, and LTO batteries, this BMS supports 8S-16S battery configurations, making it ideal for 24V and 48V battery systems.
Key Highlights
✅ 100A Continuous Charge & Discharge Current
✅ 2A Active Balancing Technology
✅ Inverter Communication Support
✅ CAN Bus Communication
✅ RS485 Communication
✅ RS232 Communication
✅ Bluetooth App Monitoring
✅ Supports 8S-16S Battery Packs
✅ Compatible with LiFePO4, Lithium-Ion & LTO Batteries
✅ Smart Battery Protection System
✅ Real-Time Battery Monitoring
✅ V19 Latest Version
✅ Temperature Monitoring Support
✅ Heating Function Support
✅ Longer Battery Lifespan
Product Features
Powerful 2A Active Balancing
The built-in 2A Active Balancer continuously transfers energy between cells, reducing voltage differences and significantly improving battery performance and lifespan.
Inverter Communication Ready
Supports multiple communication protocols:
* Bluetooth
* CAN Bus
* RS485
* RS232
Allowing seamless integration with compatible solar inverters and monitoring systems.
Perfect for Solar Energy Storage
Designed specifically for:
* Solar Battery Banks
* Hybrid Inverter Systems
* Off-Grid Solar Systems
* UPS Backup Systems
* Home Energy Storage
* Commercial Energy Storage
Advanced Battery Protection
Provides comprehensive protection against:
* Overcharge
* Over-Discharge
* Overcurrent
* Short Circuit
* High Temperature
* Low Temperature
* Cell Imbalance
Smart Mobile App Monitoring
Monitor battery voltage, current, SOC, temperatures, cell voltages, alarms, and charging status directly through the JK Smart BMS mobile application.
Applications
✔️ 24V LiFePO4 Battery Packs
✔️ 48V LiFePO4 Battery Packs
✔️ Solar Energy Storage Systems
✔️ Hybrid Inverter Systems
✔️ Off-Grid Solar Systems
✔️ UPS Backup Batteries
✔️ Home Energy Storage Systems
✔️ Commercial Battery Storage
✔️ Telecom Backup Power Systems
✔️ Industrial Energy Storage Projects
Frequently Asked Questions
The JK-PB2A16S10P is a Smart Battery Management System (BMS) designed to monitor, manage, and protect compatible lithium battery packs. It supports 8S to 16S battery configurations, with a 100A current rating and 2A active cell balancing.
The JK-PB2A16S10P supports 8S to 16S battery configurations, making it suitable for lithium battery packs with 8 to 16 cells connected in series.
Yes. An 8S LiFePO4 battery has a nominal voltage of approximately 25.6V, making this BMS suitable for compatible 24V-class LiFePO4 battery systems.
Yes. A typical 16S LiFePO4 battery has a nominal voltage of approximately 51.2V. Since this BMS supports up to 16S, it can be used for compatible 48V-class LiFePO4 battery systems.
The JK-PB2A16S10P is rated at 100A. Actual safe operating current depends on the battery cells, busbars, cables, connectors, terminals, temperature, and complete battery system design.
The 2A active balancing function transfers energy between individual cells to help reduce voltage differences and maintain better balance across the battery pack.
The 2A active balancing function can help:
Reduce voltage differences between cells
Improve battery pack balance
Improve usable battery capacity
Maintain more consistent cell voltages
Improve overall battery performance
Provide stronger balancing for larger-capacity battery packs
Yes. The JK-PB2A16S10P can be used for compatible LiFePO4 battery applications, provided the correct battery chemistry, series configuration, and BMS parameters are selected.
Depending on the exact product version and configuration, the JK-PB series can support compatible lithium battery chemistries such as LiFePO4, Lithium-ion, and LTO. The BMS must be configured correctly for the selected battery chemistry.
The BMS can be used in compatible applications such as:
LiFePO4 battery packs
Solar energy storage systems
Inverter batteries
Home energy storage
24V and 48V battery systems
EV and electric vehicle batteries
Electric mobility applications
Custom lithium battery packs
Yes. It can be used in compatible solar energy storage and inverter battery systems where the required current is within the BMS rating and the complete system is properly designed.
Yes, provided the battery voltage, chemistry, and current requirements are compatible. The 8S–16S range and 100A current rating make it suitable for various 24V and 48V-class electric mobility applications.
The JK-PB series is designed for applications where BMS-to-inverter communication may be required. Available communication protocols and supported inverter compatibility depend on the exact BMS version and configuration. Always verify compatibility before purchase.
JK Smart BMS models may include Bluetooth monitoring and mobile app functionality depending on the exact product version. Please verify the communication features of the specific unit before purchase.
The BMS is designed to monitor and protect compatible battery systems against abnormal conditions such as over-voltage, under-voltage, over-current, short circuit, and temperature-related conditions, according to the configured parameters and product version.
Yes, it can be suitable for a 100Ah lithium battery, depending on the battery's required charge and discharge current. The battery cells and complete system must also be capable of safely handling the required current.
No. The 2A active balancing current and 100A current rating are separate specifications.
The 2A rating refers to the active cell balancing function, while 100A refers to the BMS's rated current capability.
The BMS supports 8S to 16S configurations.
For LiFePO4 batteries, examples include:
8S = approximately 25.6V nominal
16S = approximately 51.2V nominal
Individual cells connected in series can develop differences in voltage and state of charge. Active balancing transfers energy between cells to help reduce these differences and maintain a more balanced battery pack.
Yes. 2A active balancing provides a stronger balancing capability and can be useful for compatible larger-capacity lithium battery packs. The appropriate balancing current still depends on cell capacity, cell matching, battery configuration, and application requirements.
Yes. It can be installed in a compatible new lithium battery pack. The battery chemistry, series cell count, current requirements, wiring, busbars, and BMS settings must be correctly matched.
The 100A rating represents the BMS's rated current capability. However, the complete battery system must also be designed to safely supply the required current.
For high-current applications, the battery cells, busbars, cables, terminals, connectors, fuses, and temperature management should all be appropriately rated.
The JK-PB2A16S10P is suitable for users looking for a 100A Smart BMS with 2A active balancing and 8S–16S support for compatible lithium battery systems, including solar storage, inverter batteries, EV applications, and custom LiFePO4 battery packs.
Both models support 8S–16S configurations and have a 100A current rating. The main difference is the active balancing current:
JK-PB1A16S10P: 100A / 1A Active Balancing
JK-PB2A16S10P: 100A / 2A Active Balancing
The JK-PB2A16S10P provides a higher 2A active balancing capability.
You can purchase the JK-PB2A16S10P 100A 2A Active Balancer 8S–16S BMS from Voltpro Energy, subject to product availability.
Visit www.voltproenergy.com to check product availability, specifications, and purchasing information.
When purchasing, always verify the exact JK-PB2A16S10P model, 100A current rating, 2A active balancing, and 8S–16S configuration to ensure compatibility with your lithium battery system.
