6V 100Ah LiFePO4 Lithium Battery is designed for customers looking for a reliable, long-life and high-efficiency alternative to conventional lead-acid batteries
The battery is built using EVE Grade A LiFePO4 cells selected for their quality, stability and performance
The cells feature approximately 0
28mΩ internal resistance (IR), helping provide efficient current delivery and consistent battery performance
Tip: Scroll inside the gallery to browse all images.
Product Description
PRODUCT DESCRIPTION
The Voltpro Energy 25.6V 100Ah LiFePO4 Lithium Battery is designed for customers looking for a reliable, long-life and high-efficiency alternative to conventional lead-acid batteries.
The battery is built using EVE Grade A LiFePO4 cells selected for their quality, stability and performance. The cells feature approximately 0.28mΩ internal resistance (IR), helping provide efficient current delivery and consistent battery performance.
With an 8S LiFePO4 configuration, the battery provides a nominal voltage of 25.6V and a capacity of 100Ah, giving approximately 2560Wh / 2.56kWh of nominal energy storage.
JK Smart Inverter BMS
The battery is equipped with a JK PB1A16S10P Smart Inverter BMS, providing intelligent battery monitoring, protection and management.
The BMS supports 1A active cell balancing, which helps maintain better voltage balance between individual cells. This can improve cell consistency, optimize usable battery capacity and support long-term battery performance.
The JK PB series is designed for inverter applications and supports communication interfaces such as CAN and RS485, allowing compatible inverters to communicate with the battery BMS.
High-Quality EVE Grade A Cells
The use of EVE Grade A LiFePO4 cells gives the battery a strong foundation for reliable energy storage. The approximately 0.28mΩ cell IR indicates low internal resistance and contributes to efficient battery operation.
Long Cycle Life
The battery is specified with approximately 6000 cycles, making it suitable for applications involving regular daily charging and discharging, such as solar energy storage and home backup.
Actual cycle life depends on depth of discharge, charging/discharging current, temperature, charging parameters and operating conditions.
Expandable Energy Storage
One of the major advantages of this battery is its parallel expansion capability.
Up to 10 Voltpro Energy 25.6V 100Ah batteries can be connected in parallel, subject to compatible BMS configuration, inverter capability, protection equipment, cabling and proper installation.
With 10 batteries connected in parallel, the system can provide:
25.6V × 1000Ah = approximately 25.6kWh nominal energy capacity.
This makes the system scalable for larger home, commercial and solar energy-storage requirements.
KEY FEATURES
24V 100Ah LiFePO4 Lithium Battery
25.6V Nominal Voltage
100Ah Capacity
2560Wh / 2.56kWh Energy Capacity
EVE Grade A LiFePO4 Cells
Approximately 0.28mΩ Cell IR
6000 Cycle Life
JK PB1A16S10P Smart Inverter BMS
1A Active Cell Balancing
CAN / RS485 Communication Support
Bluetooth Monitoring Support
8S LiFePO4 Configuration
Deep-Cycle Performance
High Energy Efficiency
Advanced BMS Protection
Maintenance-Free Operation
Up to 10 Batteries in Parallel
Suitable for 24V Solar & Inverter Systems
Suitable for Home & Commercial Energy Storage
PRODUCT HIGHLIGHTS
🔋 EVE Grade A Cells
Built with EVE Grade A LiFePO4 cells for reliable performance, efficiency and long-term energy storage.
⚡ 2.56kWh Energy Capacity
The 25.6V 100Ah configuration provides approximately 2560Wh / 2.56kWh nominal energy.
JK Smart Inverter BMS
Equipped with JK PB1A16S10P Smart BMS, designed for battery management and compatible inverter communication.
1A Active Balancing
The integrated 1A active balancing system helps maintain better voltage balance between cells and supports consistent battery performance.
Low Cell IR
EVE Grade A cells with approximately 0.28mΩ internal resistance provide efficient current flow and stable battery operation.
6000 Cycle Life
Designed for long-term daily cycling in solar, backup and energy-storage applications.
Expandable up to 10 Batteries
Connect up to 10 batteries in parallel to expand your total energy-storage capacity.
Inverter Communication
Compatible communication interfaces such as CAN and RS485 allow communication between the BMS and supported inverter systems.
TECHNICAL SPECIFICATIONS
Specification Details
Brand Voltpro Energy
Battery Type LiFePO4
Chemistry Lithium Iron Phosphate
Marketed Voltage 24V
Nominal Voltage 25.6V
Capacity 100Ah
Energy Capacity 2560Wh / 2.56kWh
Battery Configuration 8S
Cell Brand EVE
Cell Grade Grade A
Cell IR Approximately 0.28mΩ
Cycle Life 6000 Cycles
BMS Model JK PB1A16S10P
BMS Type JK Smart Inverter BMS
Active Balancing Yes
Balancing Current 1A
Communication CAN / RS485
Bluetooth Supported
Parallel Support Yes
Maximum Parallel Batteries Up to 10
Application Voltage Class 24V
Battery Chemistry LiFePO4
ENERGY CAPACITY
The battery provides approximately:
25.6V × 100Ah = 2.56kWh
Therefore, one battery stores approximately 2.56kWh of nominal energy.
If 10 batteries are connected in parallel:
25.6V × 1000Ah = 25.6kWh
This provides a scalable energy-storage solution while keeping the system voltage at approximately 25.6V nominal.
PARALLEL BATTERY SUPPORT
The Voltpro Energy 25.6V 100Ah LiFePO4 Battery supports parallel connection of up to 10 batteries.
Example:
Number of Batteries Approx. Capacity Approx. Energy
1 100Ah 2.56kWh
2 200Ah 5.12kWh
4 400Ah 10.24kWh
6 600Ah 15.36kWh
8 800Ah 20.48kWh
10 1000Ah 25.6kWh
Important: Parallel systems should use properly matched batteries and appropriately rated cables, busbars, fuses/breakers and disconnect equipment. The inverter must also support the resulting current and capacity.
INVERTER COMMUNICATION
The JK PB1A16S10P is an inverter-oriented BMS designed to communicate with compatible inverter systems.
Depending on the configuration, communication can include:
CAN
RS485
Bluetooth monitoring
Communication can allow compatible equipment to receive information such as:
Battery Voltage
Battery Current
State of Charge (SOC)
Cell Voltage
Temperature
Charging Status
Discharging Status
Protection Status
Note: Actual communication compatibility depends on the inverter model and supported BMS protocol.
ACTIVE CELL BALANCING
The integrated 1A active balancing technology helps maintain balance between the individual LiFePO4 cells.
Active balancing can help:
Reduce cell voltage differences
Improve cell consistency
Optimize usable battery capacity
Support long-term battery performance
Improve overall battery balance
0.28mΩ CELL IR
The battery uses EVE Grade A cells with approximately 0.28mΩ internal resistance.
Low internal resistance is beneficial because it can contribute to:
Better energy efficiency
Lower voltage drop under load
More efficient current delivery
Reduced internal power losses
Stable battery performance
Actual IR can vary slightly between individual cells and measurement conditions.
6000 CYCLE LIFE
The battery is specified for approximately 6000 cycles under suitable operating conditions.
Actual cycle life depends on:
Depth of Discharge (DoD)
Charging voltage
Charging current
Discharge current
Operating temperature
Storage conditions
Battery management settings
For maximum service life, the battery should be operated within the recommended voltage, temperature and current limits.
APPLICATIONS
The Voltpro Energy 25.6V 100Ah LiFePO4 Battery is suitable for:
Solar Applications
24V Solar Systems
Solar Energy Storage
Off-Grid Solar
Hybrid Solar Systems
Backup Power
Home Backup
UPS Systems
Inverter Backup
Emergency Power
Commercial Applications
Commercial Energy Storage
Small Business Backup
Telecom Backup
Security Systems
Other Applications
RV & Camping
Mobile Energy Storage
DIY Energy Storage
Remote Power Systems
HOME BACKUP APPLICATION
This 24V 100Ah battery can be used for compatible home backup systems to power appliances such as:
LED lights
DC fans
AC/DC fans through an inverter
Wi-Fi routers
TVs
Computers
CCTV systems
Networking equipment
Other compatible household loads
Actual backup time depends on the total load and inverter efficiency.
SOLAR ENERGY STORAGE
The Voltpro Energy 25.6V 100Ah battery is an excellent option for storing energy generated by solar panels.
During the day, solar energy can be used to charge the battery. During the evening, nighttime or grid outage, stored energy can be supplied to compatible loads through an inverter.
INSTALLATION & SAFETY
For safe and reliable operation:
Use a charger/inverter specifically compatible with 24V-class LiFePO4 batteries.
Configure the inverter according to thestall suitable fuses/breakers and disconnect devices.
Ensure correct polarity.
Do not exceed the BMS current limits.
When connecting batteries in parallel, use properly matched batteries.
Ensure batteries have similar voltage and SOC before parallel connection.
Professional installation is recommended for large battery banks.
WARRANTY
5-Year Warranty
The Voltpro Energy 25.6V 100Ah LiFePO4 Battery is backed by a 5-year warranty, subject to Voltpro Energy's applicable warranty terms and conditions.
WHO IS THIS BATTERY FOR?
This battery is ideal for:
Homeowners
Solar System Users
Solar Installers
Inverter Users
Commercial Businesses
Off-Grid Users
UPS Users
Energy Storage Customers
Solar Dealers & Resellers
Frequently Asked Questions
The Voltpro Energy 24V 100Ah LiFePO4 Battery is a premium deep-cycle lithium battery designed for 24V solar systems, inverter backup, UPS systems, home energy storage and off-grid applications. It uses EVE Grade A LiFePO4 cells and a JK PB1A16S10P Smart Inverter BMS with 1A active balancing.
Although commonly marketed as a 24V battery, its actual nominal voltage is 25.6V, based on an 8S LiFePO4 configuration.
The battery has a rated capacity of 100Ah and approximately 2.56kWh (2560Wh) of nominal energy.
The battery uses 8 LiFePO4 cells connected in series (8S). Each cell has approximately 3.2V nominal voltage, resulting in 8 × 3.2V = 25.6V.
The battery uses EVE Grade A LiFePO4 cells, selected for reliable performance, efficiency and long-term energy storage.
The specified cell internal resistance is approximately 0.28mΩ. Actual measurements can vary slightly depending on the cell and measurement conditions.
The battery is specified for approximately 6000 cycles under suitable operating conditions. Actual cycle life depends on depth of discharge, charging/discharging current, temperature and usage conditions.
The battery uses a JK PB1A16S10P Smart Inverter BMS, designed for compatible lithium battery and inverter applications.
The BMS provides 1A active cell balancing, helping reduce voltage differences between individual cells and maintain better cell balance.
Active balancing can help improve cell voltage consistency, maximize usable battery capacity, reduce cell imbalance and support stable battery performance over time.
Yes. The JK PB1A16S10P is an inverter-oriented BMS and supports communication interfaces such as CAN and RS485, depending on the exact configuration and compatible inverter protocol.
Yes. It is suitable for compatible 24V-class inverter systems. The inverter must support the operating and charging voltage range of a 25.6V LiFePO4 battery.
Yes. The battery is designed for 24V solar energy-storage systems and can be used with a compatible solar charge controller or inverter.
Yes. It can be used with a compatible 24V hybrid inverter, provided the inverter supports LiFePO4 batteries and the appropriate BMS communication protocol where required.
The battery provides approximately 2.56kWh of nominal energy, calculated as 25.6V × 100Ah.
Backup time depends on the connected load. A lower-power load will provide longer backup, while a higher-power load will reduce runtime. Inverter efficiency, battery condition and other system losses also affect actual backup time.
Yes. It can be used for compatible home backup loads such as fans, LED lights, Wi-Fi routers, televisions, computers, CCTV systems and other appliances within the inverter and battery limits.
Yes. It can be used with compatible 24V UPS systems that support LiFePO4 batteries.
Yes. According to the specified product configuration, up to 10 Voltpro Energy 25.6V 100Ah batteries can be connected in parallel.
Parallel connection keeps the voltage approximately the same while increasing the total capacity and energy storage.
Yes. Up to 10 batteries can be connected in parallel according to the specified configuration. Properly matched batteries, cables, busbars, fuses and protection equipment should be used.
No. Parallel connection keeps the nominal voltage at approximately 25.6V while increasing the total Ah capacity and available energy.
The battery is designed as an 8S 25.6V battery. Series connection should only be used if specifically approved for the exact battery, BMS and inverter configuration.
A typical 8S LiFePO4 battery uses a maximum charging voltage of approximately 29.2V. The final charging parameters should be configured according to the battery and BMS specifications.
The BMS manages and monitors the battery pack and provides protection against conditions such as overcharge, over-discharge, over-current, short circuit and temperature-related issues, depending on configuration.
Yes. Compatible inverters can communicate with the JK BMS through supported interfaces such as CAN or RS485. The inverter must support the relevant JK BMS communication protocol.
The JK Smart BMS platform supports Bluetooth monitoring, depending on the exact BMS configuration. Compatible monitoring software can provide information such as voltage, current, SOC, cell voltage and temperature.
Yes. Its LiFePO4 chemistry and 6000-cycle specification make it suitable for regular daily charging and discharging in solar energy-storage applications.
Yes. LiFePO4 is widely used in energy-storage applications because of its good thermal stability, efficiency, long cycle life and deep-cycle capability.
Yes. Compared with traditional lead-acid batteries, LiFePO4 batteries require very little routine maintenance and do not require electrolyte watering.
It can replace a compatible 24V lead-acid system when the inverter/charger supports the appropriate 25.6V LiFePO4 voltage and charging profile. Compatibility should be checked before replacement.
The Voltpro Energy 24V 100Ah battery is suitable for:
Solar Energy Storage
24V Inverter Systems
Home Backup
UPS Systems
Off-Grid Solar
Hybrid Solar Systems
Telecom Backup
Emergency Power
Commercial Energy Storage
RV & Camping Applications
Check your inverter's battery voltage range, LiFePO4 compatibility, charging voltage, maximum charging current, discharge requirements and BMS communication compatibility.
Yes. The system supports up to 10 batteries in parallel, allowing customers to expand their energy-storage capacity as their requirements increase.
Ten 25.6V 100Ah batteries connected in parallel provide approximately 25.6V 1000Ah, equivalent to approximately 25.6kWh nominal energy capacity.
Yes. Multiple batteries can be connected in parallel to create a larger energy-storage system, making it suitable for compatible commercial applications.
EVE Grade A cells are selected for their quality, consistency and suitability for high-quality lithium battery manufacturing. The specified 0.28mΩ IR also supports efficient battery operation.
It combines EVE Grade A cells, approximately 0.28mΩ IR, 6000-cycle life, JK PB1A16S10P Inverter BMS, 1A active balancing and support for up to 10 batteries in parallel in one energy-storage solution.
Yes. The Voltpro Energy 24V 100Ah LiFePO4 Battery comes with a 5-year warranty, subject to the applicable warranty terms and conditions.
You can purchase the Voltpro Energy 25.6V 100Ah LiFePO4 Battery directly from Voltpro Energy, subject to availability.
