The Voltpro Energy 12 Volt 100Ah LiFePO4 Battery is a high-performance deep-cycle lithium battery designed for solar systems, backup power, RVs, marine applications, and energy storage solutions
Equipped with a JK Smart BMS, Active Balancing technology, and Smart LCD Display for enhanced safety, efficiency, and real-time monitoring
PRODUCT DESCRIPTION
The Voltpro Energy 12
8V 100Ah LiFePO4 Lithium Battery is built using premium-grade lithium iron phosphate cells to provide
Tip: Scroll inside the gallery to browse all images.
Product Description
SHORT DESCRIPTION
The Voltpro Energy 12 Volt 100Ah LiFePO4 Battery is a high-performance deep-cycle lithium battery designed for solar systems, backup power, RVs, marine applications, and energy storage solutions. Equipped with a JK Smart BMS, Active Balancing technology, and Smart LCD Display for enhanced safety, efficiency, and real-time monitoring.
PRODUCT DESCRIPTION
The Voltpro Energy 12.8V 100Ah LiFePO4 Lithium Battery is built using premium-grade lithium iron phosphate cells to provide reliable power, long cycle life, and superior safety. Compared to traditional lead-acid batteries, it offers higher efficiency, faster charging, lighter weight, and significantly longer service life.
Featuring a JK Smart BMS with Active Balancing, the battery continuously balances individual cells to maximize capacity, improve performance, and extend battery lifespan. The integrated Smart LCD Display allows users to monitor battery voltage, current, State of Charge (SOC), temperature, and protection status in real time.
With a total energy capacity of 1280Wh, this battery is ideal for solar energy storage, UPS systems, camping, RVs, boats, backup power systems, and various off-grid applications.
Backup Performance
With a single full charge, the Voltpro Energy 12.8V 100Ah LiFePO4 Battery can provide approximately 4 hours of backup while running 4 AC/DC fans — including Khurshid, AR, Tamor, Royal, Pak Fan, Rado and similar fans — at full-speed Turbo Mode, along with 5 LED bulbs.
Backup Configuration:
4 × AC/DC Fans – Full-Speed / Turbo Mode
5 × LED Bulbs
Approx. Backup Time: Up to 4 Hours
Battery: 12.8V 100Ah LiFePO4
Energy Capacity: 1280Wh
Note: Actual backup time may vary depending on fan wattage, LED bulb wattage, inverter efficiency, battery condition, temperature and actual load.
KEY FEATURES
• 12.8V 100Ah LiFePO4 Lithium Battery
• Premium Grade LiFePO4 Cells
• Built-in JK Smart BMS
• Active Cell Balancing Technology
• Smart LCD Display Included
• Real-Time Battery Monitoring
• Deep Cycle Performance
• Lightweight and Compact Design
• Fast Charging Capability
• Maintenance-Free Operation
• Advanced Safety Protection
• Long Service Life
PRODUCT HIGHLIGHTS
✔ Voltpro Energy Premium Quality Battery
✔ 1280Wh Energy Storage Capacity
✔ JK Smart BMS with Active Balancing
✔ Smart LCD Battery Monitoring Display
✔ 6000+ Cycle Life
✔ Safe LiFePO4 Technology
✔ Ideal for Solar and Backup Systems
✔ High Efficiency and Reliable Performance
✔ Low Maintenance Operation
✔ Designed for Daily Deep Cycle Use
TECHNICAL SPECIFICATIONS
Brand: Voltpro Energy
Battery Type: LiFePO4 (Lithium Iron Phosphate)
Nominal Voltage: 12.8V
Nominal Capacity: 100Ah
Energy Capacity: 1280Wh (1.28kWh)
Configuration: 4S
BMS Type: JK Smart BMS
Balancing Method: Active Balancing
Display: Smart LCD Display
Cycle Life: 6000+ Cycles
Charging Voltage: 14.6V
Recommended Cut-off Voltage: 10V
Application: Solar Systems, UPS, RV, Marine, Backup Power, Energy Storage
APPLICATIONS
• Solar Energy Storage Systems
• Home Backup Power
• UPS Systems
• RV and Camper Vans
• Marine and Boat Applications
• Off-Grid Power Systems
• Camping Power Solutions
• Telecom Backup Systems
• DIY Energy Storage Projects
Frequently Asked Questions
The Voltpro Energy 12.8V 100Ah LiFePO4 Battery is a premium deep-cycle lithium battery designed for solar systems, inverter backup, UPS, home energy storage, RVs, camping, marine applications and other off-grid power systems. It combines EVE Grade A LiFePO4 cells, a JK Smart BMS, 1A active balancing and a 3.2-inch LCD display for reliable performance and real-time monitoring.
The battery is marketed as a 12V battery, while its actual nominal voltage is 12.8V, which is standard for a 4S LiFePO4 battery configuration.
The battery has a rated capacity of 100Ah and provides approximately 1280Wh (1.28kWh) of nominal energy.
The battery is built using EVE Grade A LiFePO4 cells, selected for high quality, reliability and long-term deep-cycle performance.
The battery is designed to provide 6000+ cycles under appropriate operating conditions. Actual cycle life depends on factors such as charging voltage, discharge depth, temperature, current and overall battery usage.
The specified cell internal resistance is approximately 0.28 mΩ, subject to normal cell measurement tolerances.
The battery features a JK Smart BMS, model B1A8S10P, providing advanced battery protection and monitoring functions.
The installed JK Smart BMS is rated at 100A, making it suitable for high-current applications when the complete battery system is properly designed.
The battery uses 1A active cell balancing. This technology helps transfer energy between cells to reduce cell voltage differences and maintain better battery balance.
The 1A active balancing system helps maintain better cell balance, improve usable battery capacity, reduce voltage differences between cells and support consistent battery performance over time.
The maximum specified continuous discharge current is 100A.
The battery supports a specified peak discharge current of up to 200A for short-duration high-current requirements. Peak current should not be treated as the continuous operating rating.
The maximum specified charging current is 60A. For optimum battery life, the charging current should be selected according to the battery system, charger and BMS settings.
The recommended full charging voltage for the 12.8V LiFePO4 battery is 14.6V. A charger specifically designed for 4S LiFePO4 batteries should be used.
Yes. The Voltpro Energy 12.8V 100Ah LiFePO4 battery is designed for solar energy storage and can be used with compatible solar charge controllers and inverter systems.
Yes. It can be used with compatible 12V-class inverters. The inverter's maximum power and DC input current should be checked to ensure they are within the battery and BMS capabilities.
Yes. The battery is suitable for compatible UPS and backup power systems, offering long cycle life and maintenance-free operation compared with traditional lead-acid batteries.
The battery provides approximately 1280Wh or 1.28kWh of nominal energy, calculated from 12.8V × 100Ah.
Yes. The battery includes an integrated 3.2-inch Smart LCD Display for convenient battery monitoring.
Depending on the BMS/display configuration, the LCD can provide information such as battery voltage, current, State of Charge (SOC), temperature, charging/discharging status and protection information.
Yes. The installed JK Smart BMS supports Bluetooth monitoring, allowing users to monitor important battery parameters through a compatible mobile application.
Yes. LiFePO4 batteries do not require the regular watering and maintenance associated with traditional lead-acid batteries.
LiFePO4 chemistry is widely used for energy-storage applications due to its strong thermal and chemical stability. The integrated JK Smart BMS also provides battery protection functions. Proper installation, charging and electrical protection are still essential.
Yes. Its 6000+ cycle-life specification and deep-cycle LiFePO4 chemistry make it well suited to regular daily charging and discharging applications such as solar energy storage and home backup power.
Backup Performance
With a single full charge, the Voltpro Energy 12.8V 100Ah LiFePO4 Battery can provide approximately 4 hours of backup while running 4 AC/DC fans — including Khurshid, AR, Tamor, Royal, Pak Fan, Rado and similar fans — at full-speed Turbo Mode, along with 5 LED bulbs.
Backup Configuration:
4 × AC/DC Fans – Full-Speed / Turbo Mode
5 × LED Bulbs
Approx. Backup Time: Up to 4 Hours
Battery: 12.8V 100Ah LiFePO4
Energy Capacity: 1280Wh
Note: Actual backup time may vary depending on fan wattage, LED bulb wattage, inverter efficiency, battery condition, temperature and actual load.
According to the specified product configuration, this battery is not designed for series or parallel connection. It should be used as a standalone 12.8V 100Ah battery unless Voltpro Energy specifically confirms another configuration.
The battery is equipped with a 150A-rated battery terminal, providing a robust connection for high-current battery cables.
The battery is housed in a heavy-duty 16-gauge metal box, designed to provide a strong and durable enclosure for the internal battery components.
Yes. The metal enclosure features powder coating, providing a durable finish and helping protect the enclosure during normal use.
Yes. The battery weighs approximately 13 kg and is designed with a carry handle for easier handling and installation.
The battery is suitable for:
Solar Energy Storage
Home Backup Power
Inverter Systems
UPS Systems
RVs and Camper Vans
Camping
Marine and Boat Applications
Off-Grid Power Systems
Telecom Backup
DIY Energy Storage
Emergency Backup Power
LiFePO4 technology provides advantages such as longer cycle life, higher usable energy, faster charging capability, lower maintenance requirements and significantly lower weight compared with many traditional lead-acid battery solutions.
Yes. The Voltpro Energy 12.8V 100Ah battery is specifically designed as a deep-cycle LiFePO4 battery for repeated charging and discharging applications.
Yes. Its 1280Wh energy capacity, 100A BMS, 1A active balancing and LiFePO4 chemistry make it suitable for compatible off-grid solar and energy-storage systems.
The Voltpro Energy 12.8V 100Ah LiFePO4 Battery comes with a 5-year warranty, subject to the applicable warranty terms and conditions.
Yes. Voltpro Energy offers this battery at competitive wholesale pricing in Pakistan. Customers looking for bulk quantities can contact Voltpro Energy for the latest wholesale quotation and availability.
Voltpro Energy focuses on providing quality lithium battery solutions at competitive prices. This battery combines EVE Grade A cells, JK Smart BMS, 1A active balancing, 3.2-inch LCD monitoring, 6000+ cycle life, a heavy-duty 16-gauge powder-coated metal enclosure and a 5-year warranty.
Voltpro Energy offers this battery at highly competitive wholesale pricing in Pakistan. Customers can compare the battery's specifications, build quality and price with other available options in the market to evaluate its overall value.
You can purchase the Voltpro Energy 12.8V 100Ah LiFePO4 Battery directly from Voltpro Energy, subject to availability.
A: With a full charge, the Voltpro Energy 12.8V 100Ah LiFePO4 Battery can provide approximately 4 hours of backup while running 4 AC/DC fans — including Khurshid, AR, Tamor, Royal, Pak Fan, Rado and similar models — at full-speed Turbo Mode, along with 5 LED bulbs. Actual backup time may vary depending on the exact fan and bulb wattage, inverter efficiency, battery condition and other connected loads.
Visit www.voltproenergy.com for product information, availability and purchasing details.
